How do I calculate my home electrical load?

Add up the wattage of all appliances running simultaneously. Divide total watts by 1000 to get kilowatts. Multiply by hours used per day to get kWh consumption.

What size circuit breaker do I need?

Multiply your load amps by 1.25 for the minimum breaker size. A 20-amp circuit needs a 25-amp breaker minimum. Always round up to the next standard breaker size.

What wire gauge do I need for a 20 amp circuit?

A 20-amp circuit requires 12 AWG copper wire minimum. For runs over 50 feet, use 10 AWG to prevent voltage drop.

How do I calculate voltage drop?

Voltage drop = (2 x wire length x current x resistance per foot). Keep voltage drop under 3% for branch circuits and under 5% total for feeders and branch circuits combined.

Ohm's Law states that Voltage = Current x Resistance (V = I x R). Use it to calculate any unknown electrical value when two values are known.

Electrical Calculators Archives

Electrical Calculators

Sub Panel Sizing Calculator Guide for Homeowners

What Is a Sub Panel and Why Does Size Matter? A sub panel sizing calculator is an essential tool for […]

Sub Panel Sizing Calculator Guide for Homeowners Read Post »

Electrical Calculators

Garage Electrical Requirements NEC Guide

What Are the Basic Garage Electrical Requirements Under the NEC? Understanding garage electrical requirements according to the National Electrical Code

Garage Electrical Requirements NEC Guide Read Post »
